AIR OIL SEPARATOR FOR ELGI

AIR OIL SEPARATOR FOR ELGI Manufacturers in Ahmedabad

We are also supply in Andhra Pradesh, Arunachal Pradesh, Assam, Bihar, Chhattisgarh, Goa, Gujarat, Haryana, Himachal Pradesh, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Manipur, Meghalaya, Mizoram, Nagaland, Odisha, Punjab, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Uttar Pradesh, Uttarakhand, and West Bengal

The Air Oil Separator in an ELGi Screw Air Compressor is a critical component that removes oil from compressed air, ensuring clean and dry air output while recycling the separated oil back into the compressor system.

1. Product Specifications:

Type: Oil Mist Separator

Filter Media: High-Efficiency Glass Fiber / Synthetic Fiber / Coalescing Media

Outer Material: Galvanized Steel / Stainless Steel Mesh for Durability

Filtration Efficiency: 99.9% (removes oil particles ≤ 3 ppm)

Initial Pressure Drop: ≤ 0.2 bar

Max Operating Pressure: 7 - 16 bar (100 - 230 PSI)

Oil Carryover: ≤ 3 mg/m³

2. Dimensions & Compatibility:

Outer Diameter (OD): Varies by model (120mm – 300mm)

Inner Diameter (ID): Exact fit for ELGi compressor housing

Height (H): Varies by model

Mounting Type: Flange / Threaded / Spin-on

Compatible with:

✅ ELGi EN Series (5-100 HP)

✅ ELGi EG Series (15-250 HP)

✅ ELGi EV & OF Series (Oil-Free & Variable Speed Models)

3. Features & Benefits:

✅ Removes oil mist & vapor effectively – Produces clean, high-quality air

✅ Improves compressor efficiency – Reduces oil loss and extends lubricant life

✅ Extends airend & filter life – Prevents contamination of downstream equipment

✅ Long service life – High dust-holding capacity for extended operation

✅ Low pressure drop – Ensures energy-efficient performance

4. Applications:

Industrial Air Compressors – Manufacturing, Pharmaceuticals, Food Processing, Automotive, Textile, etc.

5. Replacement Interval:

Recommended Change: Every 2,000 – 4,000 hours or as per compressor manual
